Industrial Dye-Sublimation Printer — 2000 mm, 16 Heads
S8000 (i3200)
Sixteen Epson i3200 heads in a 2×8 array, available with either the A1 or the faster A1-2 head generation.
- Print width
- 2000 mm
- Max productivity
- 600 m²/h (A1) · 800 m²/h (A1-2)
- Ink configuration
- Up to 10 colours from a 10 L bottle supply
Connect with us for a quotation tailored to your production.
Introduction
The S8000 in its i3200 build is a 2000 mm industrial dye-sublimation printer carrying sixteen Epson i3200 heads in a 2×8 array. It comes in two head generations on the same frame: the A1, and the second-generation A1-2, which lifts four-colour single-pass output from 600 to 800 m²/h. Media runs on a honeycomb suction deck over a tower support structure, driven by a magnetic-levitation system on THK soundproof double guides, with automatic ink feed under negative-pressure control and double-layer infrared hot-air drying. It is a three-phase machine on a 4100 × 2400 × 1850 mm footprint, sized for a dedicated production room rather than a corner of a shop.
Core advantages
- Two head generations, one frame Specify sixteen Epson i3200-A1 heads, or the second-generation A1-2 for roughly a third more four-colour production speed on the same machine.
- Honeycomb suction deck The honeycomb suction platform holds media flat against the deck so it prints without creasing.
- Tower support structure Tower support reinforces the machine body within a 0.03 mm precision tolerance, keeping printing and jetting consistent under load.
- Magnetic-levitation drive THK soundproof double guides with a magnetic motor and magnetic grid system reduce jitter and vibration at high carriage speed, and cut noise.
- Jumbo roller with constant tension Large-diameter brushless rubber roller transfer with automatic tension adjustment per material, unwinder to Φ1000 mm and rewinder for ten thousand metres of three-stage tension media.
- Automatic negative pressure control Negative-pressure controller with reservoir and sensor holds accuracy within 0.02 kPa, unaffected by altitude or atmospheric conditions.
- Three-tier print head protection Three-tier protection plus one-touch intelligent print head washing and an automatic cleaning and moisturising component.
- Intelligent thermal cycle drying Front and back side drying controls media surface temperature, improving drying efficiency to keep pace with print speed.
Technical specifications
Print heads
| Category | Epson i3200-A1 Hi-res | Epson i3200-A1-2 Hi-res |
|---|---|
| Quantity | 16 pieces |
| Arrangement | 2×8 |
Print media
| Max printable width | 2000 mm |
|---|---|
| Max media width | 2050 mm |
| Media type | dye sublimation printing paper, titanium dioxide paper, wallpaper, film |
| Media GSM | 22-110 g/m² |
| Media thickness | 0.02-0.5 mm |
Ink
| Ink type | dye sublimation ink, pigment ink |
|---|---|
| Colours | cyan, magenta, yellow, black, light cyan, light magenta, light black, grey, fluorescent red, fluorescent yellow |
| Ink tank | 10L/bottle |
| Ink feeding | automatic ink feeding and automatic negative pressure control |
Software
| Production software | optional software includes TexPrint, NeoStampa |
|---|---|
| File format | TIFF/JPG/EPS/PDF, colour mode support RGB and CMYK |
Function configuration
| Platform supporting structure | tower support structure |
|---|---|
| Printing deck | honeycomb uniform suction printing platform 3.0 |
| Magnetic levitation drive system | THK sound proof double guides, magnetic motor, magnetic grid system |
| Print head protection system | Three-tier protection |
| Cleaning and moisturising | automatic cleaning and moisturising integrated component |
| Tension roller transfer system | press roller: Rubber roller φ160mm/220mm (cylinder) / unload: MAX up to Φ1000mm / rewinder: MAX up to Φ450mm |
Working environment
| Drying | Double layer Infrared hot air circulation |
|---|---|
| Electrical | 380VAC±5%, Three phase five wire/220VC, 50/60HZ |
| Power | Printer 6KW, Dryer 10KW |
| Compressed air | 0.5~0.7Mpa, 0.15 m³/hr (Dry, oil-free and steam-free) |
| Temperature / humidity | recommended temperature 15-30 °C, Humidity 50%-80% (No condensation) |
Size and weight
| Size | 4100 × 2400 × 1850 length × width × height (mm), 10,000 Jumbo roller included |
|---|---|
| Weight | approximately 1500KG |
Max productivity
| Epson i3200-A1 hi-res, 16 | Epson i3200-A1-2 hi-res, 16 | |
|---|---|---|
| Configuration | 2×8 | 2×8 |
| 4-colour, 360*1200dpi (1 pass) | 600 m²/h | 800 m²/h |
| 4-colour, 720*1200dpi (2 pass) | 300 m²/h | 400 m²/h |
| 6-colour | NO | NO |
| 6-colour | NO | NO |
| 8-colour, 360*1200dpi (2 pass) | 300 m²/h | 400 m²/h |
| 8-colour, 360*1800dpi (3 pass) | 200 m²/h | 260 m²/h |
Application fields
- Fashion & garment
- Sportswear & activewear
- Home textiles
- Cushions & dakimakura
- Tablecloths
- Floor mats
- Curtains
- Soft signage
- Wallpaper
