UV DTF Printer — 620 mm Gold Foil
UV-cured AB film and gold foil, peel-and-stick onto glass, metal, packaging and cases.
- Print width
- 620 mm
- Max productivity
- 4 m²/h (i1600 × 4) · 8 m²/h (i3200 × 4)
- Ink configuration
- UV ink — CMYK + W + V + GV
Connect with us for a quotation tailored to your production.
Introduction
UV DTF is a different business from textile DTF: instead of pressing ink into fabric, it prints UV ink onto an A film, cures it, laminates a B film over the top and produces a transfer that peels off and sticks onto a hard surface. Glass, metal, packaging, phone cases — anything with a smooth face, and no heat press or powder involved. This 620 mm machine carries four Epson heads with a fixed division of labour: one for CMYK, one for white, one for varnish and one for GV, all laid down in the same pass. Gold foil runs alongside the A+B film. An integrated suction panel holds the media flat, a white-ink stirrer and circulation loop keeps the white in suspension, and front, middle and rear heaters plus hot stamping are each controllable on their own.
Core advantages
- Four heads, four jobs Head 1 for CMYK, head 2 for white, head 3 for varnish, head 4 for GV — colour, white and varnish are output simultaneously, which streamlines production.
- Peel and stick, no heat press UV-cured A+B film with gold foil produces a transfer that applies by hand — no press, no powder, no shaker.
- Integrated suction panel Material is held down through printing, keeping the process stable and secure.
- White ink stirrer and circulation A dedicated white-ink circulation component keeps pigment in suspension. The stirrer is designed to keep running even when the printer is powered off.
- Quiet rails High-precision noise-reducing THK rails from Japan — better print quality and a quieter room to work in.
- Constant tension feeding Keeps material tension even and wrinkle-free so the machine prints stably through a run.
- High-precision control board High-speed board with a stable network port, improving print accuracy and head life span.
- Heavy carriage frame Thickened integrated lifting trolley frame — the trolley lifts as a whole, which makes servicing straightforward.
+1
- Protected cable run High-strength cable drag chain built for reciprocating motion, protecting the cables and pipes inside it.
Technical specifications
These are the rated figures for this machine. For anything you don't see here, talk to us — we'll help you size the right machine for your production.
Product specifications
Speed figures are m²/h as written on the sheet.
| Print head | EPSON I1600*4 | EPSON I3200*4 |
|---|---|
| Max speed | 4 m²/h | 8 m²/h |
| Ink types | UV Ink |
| Max print width | 620 mm |
| Print media | A+B Film + Gold FILM + Waste Discharge Film |
| RIP software | Maintop, Photoprint or other optional |
| Data interface | HI-USB3.0 / Gigabit Ethernet port |
| Media heater | Front / Mid / Rear Heaters / Hot stamping heating (individually controllable) |
| Power supply | AC 110/220V ± 10%, 50Hz/60Hz |
| Power | 2000W |
| Operating environment | Temperature: 20-30 °C. Humidity: 35%RH-65%RH |
| Language of operating system | English |
Ink and process
| Ink set | UV INK CMYK+W+V+GV |
|---|---|
| Head assignment | Head 1 CMYK, head 2 White, head 3 Varnish, head 4 GV |
| Process | UV-cured AB film with gold foil, peel and stick |
| Prints onto | Glass, metal, packaging, phone cases |
Application fields
- Packaging
- Gifts
- Glass & metal branding
